4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines

Name: 4 Work Stations Martindale Abrasion Tester Pilling Textile Testing Machines
Brand: YUYANG
Price: 1 USD

China 4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines wholesale

Brand Name : YUYANG

Model Number : YY824

Certification : GB/T4802.1-2008, DIN 53863.2

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, L/C, Western Union

Supply Ability : 10 sets per month

Delivery Time : 5-10 work days

Packaging Details : Plywood Box

Product Name : Textile Testing Equipment

Usage : Martindale Abrasion Test

Specimen size : 112.8mm with area 100cm2

Rubbing times : 1~9999S

Rubbing speed : 60 RPM

Power supply : AC220V 50Hz 60W

Weight : 35Kg

Dimensions : 540*250*345 mm (L*W*H)

Contact Now

4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Equipment

Description:

1. This tester can check the abrasion and pilling capability for various textile products rubber and outside layer, lining or underlayer of the footwear or the similar fabric.

2. Using area: Martindale abrasion and pilling tester to test the abrasion of of the lining, textiles and shoes leather

Features:

1. Driven by synchronous motor, less maintenance
2. Provided different pressing weight with 490cN, 590cN and 780cN
3. Rubbing times is presettable and duly displayed on LED panel.
4. Stop automatically after reaching preset rubbing times.
5. Rubbing times can be accumulated when testing
6. Two working mode, rubbing times increase from 1 or decrease from preset times
7. The effective length of brush adjustable to control rebbing effects

Standard:

GB/T4802.1-2008, DIN 53863.2

Specifications:

1. Pilling trajectory: circular track of 40mm diameter

2. Brush with adjustable height: 2~12mm

3. Pressure for specimen:

Chemical Fiber fabric: 590cN

Combed wool fabric:780cN

Crude wool fabric 490cN

4. Specimen size: 112.8mm with area 100cm²

5. Rubbing times: 1~9999S

6. Rubbing speed: 60 RPM

7. Power: AC220V 50Hz 60W

8. Dimension: 540*250*345 mm (L*W*H)

9. Weight: 35KG

10. Accessories: power line 1pcs

4 Work Stations Martindale Abrasion Tester / Pilling Textile Testing Machines
